Frame:
Tubular steel trellis main frame. Fabricated, bolt-on aluminium rear subframe.
-
Swingarm:
Twin-sided, cast aluminium alloy
-
Front Wheel:
Spoked tubeless, 21 x 2.15 in
-
Rear Wheel:
Spoked tubeless, 17 x 4.25 in
-
Front Tyre:
Bridgestone Battlax Adventure 90/90-21
-
Rear Tyre:
Bridgestone Battlax Adventure 150/70-R17
-
Front Suspension:
Showa 45mm upside down forks, manual preload, rebound and compression damping adjustment, 240mm travel
-
Rear Suspension:
Showa rear suspension unit,manually adjustable preload and rebound damping, 230mm wheel travel
-
Front Brake:
Twin 320mm floating discs, Brembo Stylema 4 piston Monobloc calipers. Radial front master cylinder, Optimised Cornering ABS
-
Rear Brake:
Single 255mm disc. Single piston sliding caliper. Optimised cornering ABS
